Align RH70E56XW TB70 Super Combo (blades, motor, 130A ESC, metal cased servos, flybarless unit included)

$2,275
Buy
Condition: New
Type: Buy
Payment: Cash, Bank Deposit, Others
Location: Hamilton
Posted On: 28 Mar 2025, 10:28 AM
Category: Toys & Hobbies
Shipping: Pick Up Share: Share on Facebook Share on Twitter Share on Reddit Share via Email

 Report this page

Posted By:

HobbyHangar

0% Positive (0)

** Price Estimate only**. . Focus Shots. . . . . . . . . Electric equipment. ●RCE-LB130A Brushless ESC x 1. ●850MX Brushless Motor(490KV/4535) x 1. ●DS820M High Voltage Brushless Servo x 3. ●DS825M High Voltage Brushless Servo x 1. ●Microbeast PLUS Flybarless system x 1. Specification. ●Length: 1356mm. ●Height: 358mm. ●Width: 187mm. ●Main Blade Length: 650-730mm. ●Main Rotor Diameter: 1542mm. ●Tail Length: 105-115mm. ●Tail Rotor Diameter: 279mm. ●Motor Belt Pulley: 23T. Belt Pulley: 50T. ●Front Drive Main Shaft: 15T. ●Main Drive Gear: 62T. ●Autorotation Tail Drive Gear: 28T. ●Tail Drive Gear: 23T. ●Drive Gear Ratio: 8.96:1:5.0. ●Max RPM(approx.): 2290RPM. ●Frame Weight: Approx. 2.3kg. ●Flying Weight(With Battery): Approx. 4.9kg (ALIGN 12S 5200mAh). Accessories. ●TB70 Kit Set x 1 set. ●700 Carbon Fiber Blades x 1 set. ●105mm 3K Carbon Fiber Tail Blades x 1 set. ●850MX Brushless Motor(490KV/4535) x 1. ●DS820M High Voltage Brushless Servo x 3. ●DS825M High Voltage Brushless Servo x 1. ●RCE-BL130A Brushless ESC x 1. ●Microbeast PLUS Flybarless system x 1. . Radio transmitter and electronic equipment required for assembly. ●Transmitter(6-channel or more, helicopter system). ●Receiver(6-channel or more). ●RCC-6CX Intelligent Balance Charger. ●22.2V 6S 4000~4800mAh Li-Po Battery x 2. ●Digital Pitch Gauge. ●Multi-function Tester
